This is the AdaptX. The only 3in frame that can be adapted from a freestyle quad to a race quad in the same kit.

The AdaptX has two configurations. Battery on top or battery on bottom. The camera mount lets you adjust between 35 degrees for freesytle and 50 degrees for racing.

In its freestyle configuration the AdaptX is perfect for flying in just about any outdoor environment. Its power to weight lets you tryout new tricks without risking larger quads with more expensive action cameras.

In its racing configuration the AdaptX has the same motor to motor distance as a tiny trainer spec class quad. Meaning that you can take it to spec races without having to buy and build another race set up. If spec racing isn’t your thing the AdaptX offers a durable platform to practice your racing lines without having to risk your more powerful, more expensive race quds. Then when you a ready to go to a race you can be confident in your skills since you have been practicing with the AdaptX

The AdaptX uses 25x25 mounting for whoop style aios and has room for analog or HD vtx's.

The AdaptX 3d printed files can be found here: https://www.thingiverse.com/thing:7078336/files

All the components neccesary to assemble an AdaptX Frame. Each kit contains the following:

carbon fiber parts

4x AdaptX removable arm 3mm thick

1x AdaptX bottom plate

2x AdaptX locking plate

1x AdaptX Sandwich plate

1x AdaptX top plate

Screws and hardware

4x m2x16 countersunk screws

6x m2x6 button head screws

16x m2x5 button head screws

2x m3x8 button head screws

2x m2x8 button head screws

2x m2x10 button head screws

4x m2x15 standoffs

12x m2 plastic hex nuts

3d Printed Parts

1x Universal Camera Mount

1x Battery Holder

1x VTX/receiver holder

1x Cool Fin

PID tune. Paste in CLI

# master

set gyro_lpf1_static_hz = 0

set gyro_lpf2_static_hz = 1000

set dyn_notch_count = 1

set dyn_notch_q = 500

set dyn_notch_min_hz = 140

set dyn_notch_max_hz = 550

set gyro_lpf1_dyn_min_hz = 0

set acc_hardware = NONE

set acc_calibration = 10,-14,-13,1

set baro_hardware = NONE

set rc_smoothing_auto_factor = 25

set rc_smoothing_auto_factor_throttle = 25

set dshot_bidir = ON

set motor_pwm_protocol = DSHOT300

set motor_poles = 12

set yaw_motors_reversed = ON

set pid_process_denom = 2

set simplified_gyro_filter_multiplier = 200

set osd_warn_bitmask = 8063

set osd_rssi_dbm_alarm = -95

set osd_vbat_pos = 2083

set osd_rssi_pos = 354

set osd_link_quality_pos = 3084

set osd_rssi_dbm_pos = 2051

set osd_tim_2_pos = 3596

set osd_flymode_pos = 406

set osd_throttle_pos = 2531

set osd_vtx_channel_pos = 2563

set osd_current_pos = 322

set osd_gps_sats_pos = 33

set osd_home_dir_pos = 47

set osd_home_dist_pos = 56

set osd_warnings_pos = 14357

set osd_avg_cell_voltage_pos = 3116

set debug_mode = FFT_FREQ

set vtx_band = 5

set vtx_channel = 1

set vtx_power = 1

set vtx_freq = 5658

set displayport_msp_fonts = 0,0,0,0

set rpm_filter_weights = 100,25,25

set rpm_filter_q = 1000

profile 0

# profile 0

set dterm_lpf1_dyn_min_hz = 150

set dterm_lpf1_dyn_max_hz = 300

set dterm_lpf1_static_hz = 150

set dterm_lpf2_static_hz = 300

set p_pitch = 84

set i_pitch = 151

set d_pitch = 73

set f_pitch = 269

set p_roll = 81

set i_roll = 144

set d_roll = 64

set f_roll = 259

set p_yaw = 81

set i_yaw = 144

set f_yaw = 259

set angle_limit = 30

set d_max_roll = 64

set d_max_pitch = 73

set feedforward_jitter_factor = 3

set feedforward_boost = 18

set simplified_master_multiplier = 180

set simplified_d_gain = 120

set simplified_d_max_gain = 0

set simplified_feedforward_gain = 120

set simplified_dterm_filter_multiplier = 200
